Diecast Aircraft Information  Diecast Aircraft Information MetalWings Diecast Aircraft Reference by Dauntless Aviation
Hobby Master 1/72 Air Power Series
HA2805
Lockheed F-22 Raptor
43rd Fighter Squadron, Tyndall AFB,
July 2006 "01-4018"
The USAF developed a requirement for a new air superiority fighter to replace the F-15 Eagle.
Two proposals were submitted with the Lockheed Martin F-22 Raptor being selected as the
new Advanced Tactical Fighter (ATF). The aircraft is constructed using 39% titanium, 24%
composite material, 16% aluminum and 1% thermoplastic by weight. All these components
contribute to the F-22 being a light weight, extremely maneuverable, extremely fast aircraft that
uses stealth technology. The F-22 is also capable of ground attack, electronic warfare and
signals intelligence.


On September 26, 2003 the first operational F-22 Raptor # 01-4018 was delivered to the
USAF. Raptor 18 is assigned to the 43rd FS stationed at Tyndall AFB, Florida. Deactivated in
1994 the 43rd FS was re-activated on October 25, 2002 and was assigned to the 325th Fighter
Wing, Air Education and Training Command. There role will be to provide air dominance
training for the F-22 Raptor.  The 43rd can trace its beginnings back to the 43rd Provisional
Squadron of 1917.


Lockheed Martin F-22 Raptor specifications

First flight - September 7, 1997

Planned Production - 750 aircraft initial program objective

Altered plan in 1990 - 648 aircraft

Altered plan in 1994 - 442 aircraft

In 1997 Department of Defense report – 339 aircraft

In 2006 the Pentagon wanted -183 aircraft

2008 approval for 4 additional aircraft bringing the total to 187

Number built as of August 2009 - 145 (187 planned)

Role - Air superiority fighter

Crew – (1) pilot

Performance
Engines – (2) Pratt & Whitney F119-PW-100 engines producing 35,000 lbst of thrust
Speed - Mach 1.8 (super cruise: Mach 1.5)
G Limit - +9 G
Ceiling - 60,000 ft   (18,290 m)
The F-22 and other fighters can reach this altitude, but only the F-22 can perform tactical
maneuvers at this level, which is about twice the altitude at which other jets can perform tactical
maneuvers.

Dimensions
Length - 62.08 ft   (18.90 m)
Height -16.67 ft   (5.08 m)
Wingspan - 44.5 ft   (13.56 m)
Wing Area - 840 sq ft   (78.04 sq m)
Horizontal Tail-span - 29 ft   (8.84 m)

Weights
Empty Weight - 31,670 lb   (14,365 kg)
Maximum Takeoff Weight - 60,000 lb   (27,000 kg)

Armament
Internal
(1)  20mm Cannon
(4)  AIM-9 Sidewinders (side weapon bays)
(4)  AIM-120A AMRAAM (internal ventral bay)
(6)  AIM-120Cs (internal ventral bay)
(6)  GBU-32 JDAM PGMs (internal ventral bay)
(8)  GBU-39 Small Diameter Bombs (250lbs ea)
External
(4)  under-wing hard-points with a maximum of 5,000lbs   (2,270kg) of mission-specific
weaponry or fuel drop-tanks.

Die-cast metal.
Superb detailing in 1/72 scale.
Pre-painted with pad applied markings.
Fully assembled.
Weapons that are not permanently attached.
Display stand included.
Option to display model with wheels up or down.
Minimum use of plastic.

"interchangeable weapon bays (2 sidewinders, 6 AIM-120Cs)
realistic pilot figure"
